Name: Air Conditioning ISO CE Certificated Air Filter For Clean Room
Brand: Air Conditioning ISO CE Certificated Air Filter For Clean Room
SKU: air filter
Price: 1 USD
Availability: InStock
Rating: 4.8 (180 reviews)

Eigenschaften Galerie Produkt-Beschreibung Fordern Sie ein Zitat

Eigenschaften

Technische Daten

Condition: New

Efficiency: 90%

Construction: Panel Filter

Filtration Grade: Pre Filter

Medium Material: Synthetic Fiber

Porosity: 5um

Model Number: air filter

Dimension(L*W*H): Customized Size

Weight: Light Weight

Warranty: 12 Months

After-sales Service Provided: Engineers available to service machinery overseas

Zertifizierung: SGS

Application: Air Conditioning

Product name: Air Cleaner Filter

Grundinformation

Zertifizierung: SGS

Model Number: air filter

Zahlung und Versand AGB

Packaging Details: standard exporting packing

Supply Ability: 1000000 Piece/Pieces per Month

Produkt-Beschreibung

G4 panel pleated prefilter

Product Introduction:

Standard pleated primary filter, gradient-type structure to provide maximum airflow filter area, which is five times of the plane-type filter, welded steel protect net using surface rust treatment, can be well fixed linear pleated structure, protect filter media not punctured and prevent media not deformed due to excessive pressure, to ensure that filter surface is fully utilized. Can be common or moisture-proof paper frame, recycled or incinerated after use, non-pollution, environmental compliance.

Features:

Large filter area

long using life

large air volume

low resistance

large dust holding capacity

Applications: Air conditioning systems primary filtration, the Pre-filter in multi-stage filtration system

Material and operation conditions:

Media	Synthetic fiber
Sealant	Adhesive
Frame	Aluminum/Galvanized steel/Stainless steel/ Cardboard
Protect Net	Galvanized steel/Aluminum/Stainless steel/
Filter Efficiency (EN779)	G1:40%@2.0μm; G2:65%@2.0μm; G3:85%@2.0μm; G4:90%@2.0μm.
Max. Temperature	80℃
Max. Humidity	100%

Dimension & Parameters:

Model	Size (W×H×D)mm	Air flow (m³/h)	Intital Resistance (pa)	Final Resistance (pa)	Media area (m2)	Dust Holding (g)	Efficiency
AL-P1-001	287×592×46	1400	≤25	100-200	1.23	60	G1
AL-P1-002	287×592×46	1400	≤30	100-200	1.23	70	G2
AL-P1-003	287×592×46	1400	≤40	100-200	1.23	80	G3
AL-P1-004	287×592×46	1400	≤45	150-250	1.23	100	G4
AL-P1-005	592×592×46	2800	≤25	100-200	1.23	104	G1
AL-P1-006	592×592×46	2800	≤30	100-200	1.23	104	G2
AL-P1-007	592×592×46	2800	≤40	100-200	1.23	117	G3
AL-P1-008	592×592×46	2800	≤45	150-250	1.23	222	G4

Customized design is welcome.
